Shaped for sport climbing.
The ergonomic Alpha shape combines with a curved gate to make clipping easy. Once the rope is clipped, deep rope baskets help ensure the carabiner is correctly oriented.
Carbon steel construction lets the Alpha Steel handle the heavy use of modern walls. Generous rope radii give softer catches and extend rope life, while a captive bar can be fitted for easy inspection and maintenance.
The Alpha Steel is suited to areas of high wear such as first bolts, crux bolts, or changes in direction. Place throughout the wall for the best user experience.
Tech Specs
Product Name | Product Code | Dimensions | Weight | MBS (Major Axis) | MBS (Minor Axis) | MBS (Gate Open) | Certification |
---|---|---|---|---|---|---|---|
Alpha Steel Standard | C526 | 62 x 107mm | 134g | 26kN | 9kN | 14kN | EN12275:2013 B |
Alpha Steel Captive Bar | C526CB | 62 x 107mm | 135g | 26kN | 9kN | 14kN | EN12275:2013 B |
